AVer F17-8M 8MP Full HD Document Camera

More Views

AVer F17-8M 8MP Full HD Document Camera

Availability: In stock

Only 1 left

৳46,000.00

Quick Overview

Pre Order

- Capture stunning image with 8 megapixels sensor and engaging details of video quality at 30fps
- View objects from any angle via 360° flexible gooseneck arm
- Multiple connectivity, such as VGA, HDMI, USB 2.0

Qty:

Be the first to review this product

Email to a Friend

Technical Data

Sensor	1/3.2” CMOS
Pixel Count	8 megapixels
TV Lines	1000 (max.)
Effective Pixel	3840 H x 2160 V
Frame Rate	30 fps (max)
White Balance	Auto / Manual
Exposure	Auto / Manual
Image Mode	Sharp / Graphics / Motion / Microscope
Effect	Color / B/W / Negative / Mirror / Rotate / Freeze
RGB Output	1920x1080, 1280x1024, 1280x720, 1024x768, 1280x800
HDMI Output	HD 1080p 50Hz/60Hz; HD 720p 50Hz/60Hz; 1024x768 60Hz
Optics
Focus	Auto / Manual
Shooting Area	Max. 22.83” x 12.83” (580mm x 326mm)
Zooming	27.2 Total Zoom
Image Rotation	0° / 180°
Function
Image Effect	Color / B&W / Negative / Mirror / Reverse / Freeze
White balance / exposure / night view	Auto / Manual
Picture-in-picture	Yes
Split Screen	Yes
Presentation Tools	Spotlight (Yes), Visor (Yes)
Capture Mode	Single / Continuous
Remote Control	Yes
Image Storage	240 Frames (XGA); 80 Frames (8M Pixel)
Onboard AV Recording	Yes
Onboard Annotation	No
Compatibility
Operating Systems	Windows 7 (32/64 bit), Windows 8 (32/64 bit), Windows 10 (32/64 bit), Mac OS X 10.9 or above (Intel based), Chrome OS 29 or above
Aver Software	AVer A+ Software Suite (Sphere 2, PowerPoint Plug-in, Flash-Plug-in), Sphere Lite (for Chromebook)
Interative Whiteboard Compatibility	Yes with AVerVision Flash Plug-in *certain limitations apply
Power
Power Source	DC 12V, 2A, 100-240V, 50-60H
Power Consumption	12 Watts (lamp off); 12.8 Watts (lamp on)
Lighting
Lamp Type	LED light
Input / Output Connections
RGB Input	15-Pins D-sub (VGA)
RGB Output	15-Pins D-sub (VGA)
HDMI Input	Yes
HDMI Output	Yes
Composite Video	RCA Jack (Thru optional CVBS cable)
USB	Mini-USB 2.0 (Connect to PC), Type-A (for USB drive)
SD	SD / SDHC (Up to 32GB)
DC 12V Input	Power Jack
MIC Input	3.5mm jack, pink
Dimension
Operating (WxHxD)	7.87” x 20.67” x 14.96” (200mm x 525mm x 300mm) *+/- 2mm include rubber foot
Folded (WxHxD)	9.05” x 2.87” x 12” (230mm x 73mm x 305mm) *+/- 2mm include rubber foot
Weight	5.51 lbs (2.5kg)

Package includes:

1 x AVer F17-8M Document Camera, 1 x Power Adapter 12V 2A, 1 x Remote Control (with batteries), 1 x RGB Cable, 1 x Mini USB Cable, 1 x Software CD, 1 x Quick Guide
