Specifications:
Door station/System parameters
- Operation system: LINUX
- ProcessorEmbeded high performance processor
- Memory/
- RAM512 MB
- ROM4 GB
Door station/Video parameters
- Supplement lightIR light, up to 3 m
- Resolution: Main stream: 4MP(2688x1520P), 2MP(1920x1080P), 1MP(1280x720P)
Sub stream: 2MP(1920x1080P), 1MP(1280x720P), 0.3MP(640x480P) - Lens1
- FOVHorizontal: 150°; Vertical: 75°
- Video compression standardH.264; H.265; MJPEG
Door station/Audio parameters
- Volume adjustmentAdjustable
- Audio Performance50cm 80dB (Maximum: 50cm 83dB)
Door station/Capacity parameters
- User capacity2000
- Card capacity10000
Door station/Network parameters
- Network protocolTCP/IP, SIP, RSTP, IPV6, ONVIF
- Wi-Fi2.4GHz
- BluetoothSupported
- Wi-Fi ProtocolIEEE802.11b;IEEE802.11g;IEEE802.11n;IEEE802.11ax
- Wi-Fi TypeWiFi 6
Door station/Authentication parameters
- Card TypeM1 Card
- Card reading frequency13.56 MHz
- Authentication modeCard;Bluetooth;PIN Code;Hik-Connect;Indoor Station
- Card Reading DistanceM1card:2to2.5cm
Door station/Application
- Mobile APPHik-Connect
- Motion DetectionSupport
- PlaybackSupport
- Call ElevatorSupport
- Smart FeaturesSound Classification Detection: Scream, Glass Breaking Sound, Crying Sound (Recommended Detection Distance: 3 m)
Door station/Device interfaces
- Network interface1 RJ-45, 10/100 Mbps self-adaptive
- Exit button1
- Lock control2 relay, Max. 30 VDC 2 A
- RS-4851
- Door contact input1
- Alarm input4(includeExit button and Door contact input)
- Alarm output0
- TAMPER1
- TF cardSupport TF card, up to 128 G
- Supported TF FormatFAT32;exFAT
Door station/General
- Button1 physical button(s)
- Indicator3
- Power consumption＜ 10 W
- Working temperature-40 °C to 60 °C (-40 °F to 140 °F)
- Working humidity10% to 90% (no-condensing)
- Application environmentOutdoor
- Dimension (W × H × D)164 mm × 69 mm × 24.7 mm (6.46" × 2.72" × 0.97")
- Protective levelIP65
- Installation Surface mounting
- Without package: 273 g (0.61 lb),With package: 431g (0.95 lb)
- Material: Front Shell and Rear Shell Material: Plastic
Viewing Window Panel Material: Glass - Power supply12 VDC, 1.2 A,IEEE 802.3 at, standard PoE
- LanguageEnglish, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese (Taiwan), Latin American Spanish
- Power Supply OutputMax. 12 VDC, 1 A
Indoor station/Audio parameters
- Audio input1 built-in omnidirectional microphone
- Audio output1 built-in loudspeaker
- Audio qualityNoise suppression and echo cancellation
- Audio compression standardG.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1
- Audio compression bitrate16~64Kps
Indoor station/Network parameters
- Wired network 1 RJ-45, 10/100 Mbps self-adaptive
- Wireless network2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
- Network protocolTCP/IP, SIP, RTSP
Indoor station/Device interfaces
- RS-4851 RS-485 (Half duplex)
- Alarm input8-ch alarm inputs
- Relay output2
- TF cardSupport TF card, up to 128 G
Indoor station/General
- Power consumption≤ 5 W
- Power supply12 VDC, 1 A,IEEE802.3af, Standard PoE
- Working temperature -10 °C to 50 °C (14 °F to 122 °F)
- Working humidity10% to 90% (no-condensing)
- Dimension (L x W x H)174.99 mm × 113.49 mm × 21 mm (6.89" × 4.47" × 0.83")
