Trendnet Network IP Camera (TV-IP651W)

Wireless PTZ Network Camera

TV-IP651W

Wi-Fi compliant with IEEE 802.11n standard
Backwards compatible with IEEE 802.11g and IEEE 802.11b devices
One touch WPS connection button
1 x 10/100Mbps Auto-MDIX RJ-45 port (for optional wired installation)
Power and activity LED indicators (can be disabled)
1-way audio
4x digital zoom
Pan left or right 170° for a total of 340°
Tilt the camera up 90° and down 25° for a total of 115°
Dynamic DNS support
Supports up to 640 x 480 pixel resolution at up to 20 frames per second
Image controls: Brightness, contrast, saturation, flip image vertically, mirror image horizontally
Define a recording schedule or motion detection recording
Create motion detection fields of any shape over the viewing area
Supports TCP/IP networking, Email, HTTP, and other Internet protocols
System controls:

Define up to 64 user login accounts
Set the date and time or synchronize with an NTP server

Supports wireless encryption up to WPA2-PSK
Quick Universal Plug and Play (UPnP) installation
Complimentary TRENDnetVIEW Pro software: manage up to 32 cameras *
TRENDnetVIEW Pro software compatible with Windows operating systems
Mounting base and mounting hardware included
3-year limited warranty

The Wireless PTZ Network Camera, model TV- IP651W, provides video monitoring over a large area. Pan the camera side-to-side a remarkable 340 degrees and tilt up-and-down 115 degrees from any Internet connection. Pan the camera side-to-side a remarkable 340 degrees and tilt up-and-down 115 degrees from any Internet connection. Wireless n technology provides unsurpassed wireless coverage and improved streaming video quality. Add this camera to your wireless network at the touch of a button with Wi-Fi Protected Setup (WPS).

Record 640 x 480 pixel (VGA) video at up to 20 frames per second (fps). Manage up to 32 TRENDnet cameras with the included complimentary camera management software. Advanced features include adjustable motion detection recording areas, email alerts, scheduled recording sessions, pan/tilt Auto-Patrol, date-and-time overlays, one-way audio, an adjustable lens, and four times digital zoom. A wall/ceiling mounting kit is included and the camera’s off white housing blends into most environments.

TRENDnetVIEW Pro Camera Software Features

Manage up to 32 cameras
Compatible with Windows and Microsoft Server 2008
Multiple language support
Camera Viewing

Preset viewing modes
Program custom viewing modes
Full screen view
Drag and drop live feeds to a new location
Program camera cycle viewing sequence
Motion detection brings video forward
Side, top, and bottom tool bars can be hidden
Web based access from smart phones and tablets

Recording options

Program weekly recording schedules
Motion detection recording

Define motion detection areas of any shape
Define motion detection sensitivity

Event trigger recording
Date and time overlay
Save a single video stream to multiple locations simultaneously
Define recording quotas by recording time or space allocation
Disk clean feature condenses and optimizes old files
Real time recording stats to help manage files

Search and Playback

Navigation timeline provides a quick visual reference to the recorded content
Search continuous recordings by motion
Search recordings by motion within a defined field (a portion of the viewing area)
Time lapse playback search
